71080 Whelen Aircraft Beacon

 71080 Series Whelen LED Aircraft Beacon

71080 LED beacons from Whelen are FAA TSO'd self-contained LED anti-collision lights (Ref. Class I - 150 effective candlepower). They are designed to replace existing beacons utilizing a 2-1/2 diameter footprint.

71080 Whelen Aircraft Rotating Beacon Replaces Strobe

These LED's may also be used to replace remote mounted strobe lights (ref. Whelen A470 series) to allow the removal of the strobe power supply. Internal mounting plate provided with choice of mounting holes to retrofit most existing mounting patterns.

71080 Beacon Light Aircraft Certified Approvals

• Power Consumption: 0.45 Amps @ 28 VDC
• LED Color: Aviation RED
• Weight: 1.8 lbs (816gm) (unless otherwise noted)
• Exposed Height: 2.70" (69mm)
• Lens Color: Clear glass
• Replaces: Whelen: 90044 Series and Grimes: G9950-( ), 40-0100-( ), 30-2140-( ), 40-0117-( ), 40-0127-( ), 30-2647-( )
